รายละเอียดสินค้า:
การชำระเงิน:
|
| ประเภทสายเคเบิล: | สายเคเบิลควบคุมทองแดง | ความดันเฉพาะ: | 450/750v |
|---|---|---|---|
| การกันความร้อน: | PVC | ผู้ขับ: | ทองแดง |
| เกราะ: | ลวดเหล็กชุบสังกะสี | ส่วนข้าม: | 0.75mm2 ~ 6mm2 |
| แกน: | 2 ~ 61 | ตัวอย่างฟรี: | สามารถรับรอง |
| บริษัท: | กลุ่มเซิงหัว | ยี่ห้อ: | เอส เคเบิล |
| เน้น: | PVC Insulated Armoured Electrical Cable,750V Armoured Electrical Cable,Steel Wire Armoured Electrical Cable |
||
In critical infrastructure where temperature swings, mechanical stress, and electromagnetic interference threaten operational continuity, Shanghai Shenghua Cable Group delivers uncompromising reliability. Our Multicore 450/750V Armoured Control Cable—engineered with military-grade protection and adaptive insulation—powers mission-critical systems from factory floors to underground utilities.
Conductor Flexibility
Temperature Defiance
Eco-Smart Sheathing
Technical Specifications
| Feature | Specification |
|---|---|
| Rated Voltage | 450/750V AC |
| Bending Radius | ≥15×(d+D)±5% (Multi-core) |
| Conductor Options | Class 1 (Solid), Class 2/5 (Stranded) |
| Short-Circuit Survival | 250°C for 5 seconds |
| Armor Impact Resistance | ≥3000N/10cm (Steel Tape) |
Construction:
| Conductor | Compact Stranded Copper Conductor, Class 2 as per IEC 60228 |
| Circular solid Copper Conductor, Class 1 as per IEC 60228 | |
| Flexible Stranded Copper Conductor, Class 5 as per IEC 60228 | |
| Insulation | PVC |
| Metalic Shield | Copper Tape Screen or Copper wire & copper tape Shield (optional) |
| Filler | Fillers strip |
| Wrapping Tape | Non woven wrapping tape or lsoh wrapping tape |
| Inner Covering | Extruded PVC |
| Armour | Steel Tape Armour, Steel Wire or Aluminium Wire Armor optional |
| Overall Sheath | PVC, FR-PVC, PE or LSOH |
Application:
This kind of cable could be used in security or alarm device installation or in low voltage applications such as telephone extensions and cirsuits.
Standards:
Our products could be designed to comply with IEC standard or CE, DIN, VDE, BS, AS, GB, NZS, GOST, NFC, UL, ANSI standards as customer's request.
Product Features:
1) Min. Ambient temperature for installation: -90 ° C
2) Max. Normal continuous operating temperature: 250° C
3) Max. Permissible conductor temperature at short circuit (5s. At longest): 250° C
4) Permissible bending radius:
Single core: ≥ 20(d+D)± 5%
Three core: ≥ 15(d+D)± 5%
We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
Cable is supplied in wooden reels, corrugated boxes and coils. Cable ends are sealed with BOPP self adhesive tape and non-hygroscopic sealing caps to protect the cable ends from moisture. The required marking shall be printed with a weather-proof material on the outsides of drum according to customer's requirement.
